4 Pcs Fuel Injectors 4 Holes for Suzuki 4-Stroke Outboard Engine DF 60 70 HP Escudo Grand Vitara
Package Included:
4 x Fuel Injector Nozzle Unit
Specifications:
Condition: Brand New
Replaces OEM Part #:
15710-66D00
1571066D00
15710-66D00-0000
CDH166
Replaces Johnson Evinrude OMC #: 5032693
Fitment:
Fits the following Suzuki 4-Stroke Outboard Engine:
Model Rated HP Stroke Years
DF60 60HP 4-Stroke 1998-2009
DF70 70HP 4-Stroke 1998-2009

For Car & Auto: Suzuki ESCUDO, Suzuki GRAND VITARA, Suzuki VITARA

Installation Guide:

  1. Safety First: Ensure the engine is off and cool. Disconnect the negative terminal of the battery.
  2. Relieve Fuel Pressure: Follow the manufacturer's service manual to safely relieve fuel system pressure. This is a critical safety step.
  3. Disconnect Injector: Unplug the electrical connector from the fuel injector you are replacing.
  4. Remove Fuel Rail: Detach the fuel line and unbolt the fuel rail from the intake manifold.
  5. Remove Old Injector: Carefully pull the old fuel injector from its port. Be prepared for minor fuel spillage.
  6. Prepare New Injector: Lightly lubricate the new injector's O-rings with clean engine oil before installation.
  7. Install New Injector: Press the new fuel injector firmly into its port on the fuel rail and intake manifold.
  8. Reinstall Fuel Rail: Secure the fuel rail back onto the engine and tighten the bolts to the manufacturer's specified torque.
  9. Reconnect: Reattach the fuel line and the electrical connector to the new injector.
  10. Final Checks: Reconnect the battery. Prime the fuel system by turning the key to the "On" position a few times, then start the engine and carefully check for any leaks.
